Streckkodsläsare för placering i kassadisk

SCANTECH VEGA 1020

Castor+ C-5010

The VEGA handheld bar code scanner series, with an extensive range of models, represents the new style in handheld bar code scanning.
It is a modern and ergonomically designed scanner which offers an outstanding reading performance. The VEGA scanners are available with a number of interfaces, which offers a wide range of possibilities and solution for every Point of Sale environment


Egenskaper:

Flat and rugged (height 75 mm)
Dense 5 – field, 15 lines scan pattern and scan rate of 1500 scans / second
Directional bar code reading
No need to lift and tilt a product due to the real vertical scan lines
EAS compatible

Tillbehör
DLC Glas
Horizontal Mount

Produktspecifikation:

Physical Characteristics: 75 (D) x 205 (W) x 240 (L) mm, 2.5 kg
Power Supply Voltage: 100-240 V ac, 50/60 Hz
DC input to scanner
(aux. port not in use): +12 V dc (600 mA), – 12 V dc
(25 mA), +5 V dc (300 mA)
Interfaces: USB, Powered USB, KBW, RS232
Light source: 650 nm visible laser diode
Depth of field: 300 mm
Scan pattern: 5 direction scan field,
15 lines scan pattern
Scan rate: 1500 scans/second
Barcode types: GS1 DataBar,EAN/UPC/JAN including
Add – On, Code 128, EAN 128,
Code 39, Code 32, Codabar,
Interleaved 2/5
Compatibility: EAS compatible
Operating Temperatur: 0°C - 40°C
Humidity: Relative humidity to 95%
Laser Safety: IEC 825 – 1 (1993) Class I,
U.S. 21CFR1040 Class IIa
Electrical Safety: EN 60950 (second edition),
UL1950 (third edition)
