Scantech Mica M-9030

Scantech Mica M-9030

The Scantech ID Mica M-9030 is a very compact and high performance omni-directional laser barcode scan engine ideal for built-in and Original Equipment Manufacturer (OEM) applications.
The optimized compact design makes it very easy to integrate the Mica M-9030 in many built-in and OEM applications like kiosks, AT M’s, return vending machines, price verifiers and access control terminals. The Mic a M-9030 has a multi interface, user upgradeable software and auto-sense which saves costs and improves life time.


Most compact omni-directional laser barcode scan engine in its class
Optimized design for built-in and OEM applications
Reading all common 1D barcodes, incl. GS1 DataBar, regardless of its orientation
Scantech ID STAR reconstruction software for reading of fragmented and damaged barcodes
High first scan rate
Auto-Sense function, which saves power and improves life time

High Stand & Small Stand


Dimension: 46 mm (D) x 62 mm (W) x 67 mm
Weight: 130g
Colour Options: Black, Silver
DC input to scanner: +5 V DC, 250 mA or +12 V DC, 140 mA
Power Consumption: 1.25 Watt @ +5 V DC/1.68 Watt @ +12V DC
Interfaces: RS232. KBW. USB
(HID and COM port emulation).
Powered USB (optional)
Light source: 650 nm visible laser diode
Depth of field: Up to 300 mm @ UPC/EAN 100%, PCS 90%
Scan pattern: 6 direction scan field, 24 lines
Scan rate: 2000 scans/sec
Light level: Max 4000 LUX
Barcode types: EAN/UPC/JAN + Add-on, ISBN, Code 128,
EAN 128, Code 93, Code 39, Code 32,
Codabar, Interleaved 2 of 5,
MSI-Plessey, GS1 DataBar
Operating Temp: 0°C - 40°C
Storage Temp: -20°C - 60°C
Humidity: 20% ~ 95% RH (non-condensing dew)
Laser Safety: IEC 825-1 (1993) Class I, U.S.
21CFR1040 Class IIa
Electrical Safety: EN 60950 second edition.
UL1950, c-UL (according CSA22.2.950)
Ratio: 94V-0
Radio and TV
Interference: EN 55022 Class B (1994),
FCC part 15 Class B (1992)
Radio Frequency
Immunity: EN 50082-1 (1992)
Electro Static
Discharge (ESD):IEC 801-2 (1991)
Regularity of
compliance: CE & FCC compliant
