Streckkodsläsare för placering i kassadisk

Scantech Orion O-3050

Scantech Orion O-3050

The ORION is a new presentation laser scanner which allows hands free bar code scanning and reads all popular bar code symbologies. Bar code labels are read by presenting the labels towards the scanner. Scanning labels with the OR ION hardly requires any arm movement and only little free space on the counter top is necessary. The OR ION can either be fixed on a counter surface or on a flexible stand, so its optimal for every application and environment. The OR ION has a programmable sleep mode. If the scanner is not used within a period of time, the scanner switches off automatically. The scanner can be re-activated by pressing the switch on top of the scanner


Databar decoding
Easier scanning by (‘turbo’)
boosted reading sensitivity
Increase ergonomics by enlarged
(‘doubled’) reading range (Depth of Field)
Auto-wake-up from standby mode
Flexible Foot design for easy installation,
suitable for all check-outs
Goldrush polygon for high performance,
quick start and energy-savings
Dense scan pattern
Available in Black or Light Grey Colour


Physical Characteristics:61 (D) x 135 (W) x 146 (H) mm. 135 (D) x 135 (W) x 215 (H) mm (with stand)
Weight: 500 g. with stand: 675 g
Power supply voltage: 100 – 240 V ac 50 / 60 Hz (adapter)
DC input to scanner: 12 VDC, 165 mA nominal, 95 mA standby
Interfaces: RS232, KBW, USB, Powered USB
Light source: 650 nm visible laser diode
Depth of field: 300 mm
Scan pattern: 7 direction scan field, 24 lines
Scan rate: 2480 scans / sec
Barcode types: EAN/UPC/JAN + Add-on, Code 32
(Ital. Pharmacode). Code 128, EAN 128,
Code 39 (+ full ASCII), Code 93,
Codabar, Interleaved 2/5 and GS1 DataBar
Radio and TVinterference: EN 55022 Class B (1998). + A1 (2000),
FCC part 15 Class A (1992)
Harmonic currentemissions: EN 61000-3-2 (1995) + A1 (1998) +
A2 (1998). EM-immunity: EMC Directive
89/336/EEC, EN 55024 (1998) + A1 (2001)
OperatingTemperature: 0°C - 40°C
Relative Humidity: 20% ~ 95% RH (non-condensing).
Withstands multiple drops: of 1.0 m on concrete surface
Safety: IEC 825-1 (1993) Class I, U.S.
CDRH: 21CFR1040, Class II a,
EN 60950 second edition UL1950,
c-UL (according CSA22.2.950),
Flammability rate 94V-0
