Scantech SG-15+

The Shuttle SG-15+ is an entry level, small and attractive price checker with latest technology. Interfacing is either through Wireless RF or hard wired Ethernet. The bright display has, depending on the font set, 3 or 5 lines and can display up to 20 characters per line. Size and Design (three colours) help to install the Shuttle in different environments. This flexibility of installation is enhanced by the optional Power–over–Ethernet



Wireless: WiFi 802.11 b/g/n with WPA encryption (WPA – 1, WPA – 2 personal Enterprise) through mini
Secured access to web interface by password
Ethernet: 10/100 Base – T
Audio: Play real audio samples (wav) through loud speaker
Animation: Supports animations/pictures/logos on display
Handheld scanner connection through AUX port (RS – 232)
Remote Management
Colours: Black, Silver


2D Scan engine
Exit Gate


Physical Characteristics:95 (D) x 131 (W) x 181 (L) mm
Display: High-bright blue – white, 128x64 pixels
Interfaces: Ethernet 10/100 Base – T interface,
PoE IEEE 802.3af (optional),
802.11 b/g/n using an optional
mini-PCI card, WAP encryption
(WPA – 1, WAP – 2 personal & enterprise)
Light source: 650 nm visible laser diode or red LED
Depth of field: 200 mm (= maximum reading distance)
Scan rate + pattern: Omni – directional
laser scanner: 1350 scans/sec.
CCD scanner: 270 scans/sec.
Barcode types: EAN/UPC/JAN + Add-on, Code 128,
EAN 128, Code 39 (+ full ASCII),
Code 93, Code 32, Codabar,
Interleaved 2/5, GS1 Databar, ISBN
External connection: AUX port (RS-232) for connection of
a handheld scanner
Audio: Speaker
Operating Temperature: 0°C - 40°CN
Humidity: 20% - 95% (non-condensing)
Regularity of Compliance: CE, FCC, and RoHs
