Scantech SG-20

The SG-20 is a multifunctional customer information terminal and guarantees exact product information. It provides an excellent scanning performance in combination with a large and full graphical LCD display to ensure an easy communication. The Discovery helps to sustain and increase the relation with the customer and enables the retailer to effectively provide additional information and services. The customer can retrieve specific information on actual pricing of products, total sum of purchases, bonus points status, discounts and special offers.



Programmable buttons
Compact and slim size
Ethernet and Wi-Fi Ready
3 Color and Ergonomics
Easy installation
Colours: Black, Silver, Red


Separator Box
Exit Gate


Physical Characteristics:298 (H) x 181 (W) x 100 (D) mm
Power Supply: Voltage 100-240 V ac, 50/60 Hz
Display: Back Lit STN graphical 240x128 pixels
Interfaces: RS232, RS422, RS485 and
optional Ethernet or WiFi
Light source: 630 – 670 nm visible laser diode
Depth of field: 250 mm (= maximum reading distance)
Scan pattern: Omnidirectional
Barcode types: EAN/UPC/JAN + Add-on,
code 32 (Ital. Pharmacode). Code 128,
EAN 128, Code 39 (+ full ASCII), Code 93,
Codabar, Interleaved 2/5
Operating Temperature: 0°C - 40°C
Humidity: 20% - 95% (non-condensing)
Regularity of Compliance: CE, FCC, and RoHs
Laser Safety: IEC 825-1 (1993) Class I, U.S.
21CFR1040 Class IIa
